AML ez1073pre - Fit Pin Headers to Pcbs; Long Pin Goes through PCB; Cut off Excess Pin and Solder

Cut off excess pin and solder
Long pin goes through PCB
Fit pin headers to PCBs
1 x 8-way & 1 x 10-way (Switch PCB)
10 way 8 way
1 x 4-way & 1 x 2-way (Trim Pot PCB)
1 x 4-way (Surge Control PCB)
2 x 4-way (Gain stage 3 PCB)
1 x 4-way & 1 x 3-way (Gain stage 1 & 2 PCBs)
2 way 4 way 10 way 8 way
4 way 4 way 4 way 4 way 4 way3 way 3 way
Assembly Tip:
Use a jumper (like that fitted
to J4) to hold the header in
place... solder a couple of
pins... remove the jumper..
trim the pins... then solder
the rest.
