48v LED installation

Fit the 48v indicator LED to the solder side of the PCB

such that the base of the LED aligns with the

front edge of the PCB.

“Flat” of LED

Solder Side.

Long Leg

Align front edge of LED base...

.....with edge of PCB

BACK OF PCB
