2 - 26
USER’S GUIDE Triton Wireless Hand-held Terminal
Laser Symbology Settings (SR, LR, ALR) - cont’d.
Section Setting Parameter Available Options Option Description
MSI / Plessy
(cont’d)
Check Digits 1.) One Verify single check digit
2.) Two Verify two check digits
Tx Check Digit Enabled/Disabled Enable/Disable the transmission of the
veried check digit(s)
Algorithm 1.) Mod10/Mod11 Use Mod 11 for second check digit
2.) Mod10/Mod10 Use Mod 10 for second check digit
GS1 Databar
(formerly RSS)
GS1 14 Enabled/Disabled Enable/Disable decoding of GS1
Databar (14) symbols
GS1 Limited Enabled/Disabled Enable/Disable decoding of GS1 Limited
symbols
GS1 Expanded Enabled/Disabled Enable/Disable decoding of GS1
Expanded symbols
GS1 Conversion 1.) None No conversion on GS1 symbols
2.) To UPC/EAN Convert GS1 Databar (14) and GS1
Limited: Symbols with one leading
0 will have leading 3 characters
stripped and type ID set to EAN-13;
Symbols with two or more leading
zeros will have the leading four
characters stripped and the type ID
set to UPC-A
**Laser Data Lengths Explanation
Desired Action Data Length 1 Data Length 2
Allow only one discrete
length bar code
Discrete length of symbol to
decode
0 (Zero)
Allow two discrete lengths
Higher length value Lower length value
Lengths within a range are
decoded
Lower length value Higher length value
Any length bar code is
decoded within laser
capability
0 (Zero) 0 (Zero)
