AML Triton - Triton Terminal Overview; General Specifications

1 - 1
USER’S GUIDE Triton Wireless Hand-held Terminal
Chapter 1
Triton Terminal Overview
Technical Specications
General Specications
Dimensions
8.9” L x 3.5” H x 2.3” D (225 L x 89 H x 57 D mm) without optional handle
8.9” L x 3.5” H x 8.2” D (225 L x 89 H x 208 D mm) with optional handle
Weight
17 oz (482 g)
25 oz (709 g) with pistol-grip handle
Display
160 x 160 pixel Grayscale LCD with white LED backlight
Keyboard Options
35-key Numeric Keypad
55-key Alpha-Numeric Keyboard
Data Capture & Bar
Code Scanner Options
Standard 1D “Near to Mid” Range Laser
Lorax “Near/Far” Laser
2-Dimensional Area Imager
Battery
7.4V, Lithium-Ion 2600 mAh, 19.2 Watt-hour
I/O Ports
USB Type B (Slave)
Serial RS-232 (max. rate 115200 baud)
Sound
Integrated system bell (beeper)
Operating Temperature
14° to 122° F (-10° to 50° C)
Storage Temperature
-13° to 122° F (-25° to 50° C)
Humidity
5% to 90% RH, non-condensing
Static Discharge
15 kVDC air; 4kVDC contact, all sides
Drop Rating
5 ft. (1.5M) to concrete
Sealing
IP51 (dust, drip waterproof)
Regulatory
FCC Part 15 Class A
RoHS Compliant / Pb-Free
Laser (if equipped): CDRH Class II, IEC Class 2
Architecture Specications
Microprocessor
Samsung S3C2410 32-bit ARM9 @ 202 MHz with Advanced Microcontroller
Bus Architecture (AMBA)
Memory
32 MB SDRAM @ 101MHz; 16 MB Non-volatile NOR Flash
Operating System
AML Embedded Linux OS, Linux Kernel® 2.6.39
Development
Environment
AML Triton SDK for Linux supporting C and C++ GNU GCC 3.3.5 for ARM-Linux
Fully Open-Sourced Licensing
