ADS 70 / ACR 70 D 17
Operation :
5.5 Working with the vibration rammer :
• Avoid the rammer vibrating while its butt plate is not touching ground.
• Never lift the rammer during operation !
Note :
- The moving speed can be regulated over the rammer’s inclination.
Inclination forwards = fast movement forwards
Inclination backwards = slow movement forwards
- The moving speed can as well be regulated over the pressure exerted on the
handle bar.
______________________________________________________________________________
5.6 Adjustment during breaks :
• Place the throttle lever in position „idle running“ (L; Fig. 7).
Attention :
Never leave the rammer unsupervised during working breaks !
5.7 Stopping the engine :
• Place the throttle lever „G“ to „Stop“-position and the engine will stop (Fig. 7).
• Close the fuel cock by turning it in position „0“ (Fig. 8).
______________________________________________________________________________
6.0 Recommendation for compaction works with ADS 70
The maximum layer height depends on several factors :
1. nature of the ground
2. humidity
3. grain distribution in the ground
4. grain size
For this reason, it is not possible to give exact details regarding the maximum layer height.
Recommendation : Determine the maximum layer height in each single case
by tests and by taking samples of the soil !
