ADS 70 / ACR 70 D 4
Table of contents :
1.0 Technical specifica-
tions
5
1.1 Main dimensions 5
1.2 Technical specifications 5
1.3 Noise and vibration values 6
2.0 Description
7
2.1 Fields of application 7
2.2 Modifications on the machine 7
3.0 Safety regulations
9
3.1 Proper use 10
3.2 Operating the vibration rammer 10
3.3 Safety remarks in the operating/maintenance manual 10
3.4 Warning stickers on the vibration rammer 11
3.5 Loading the vibration rammer 11
3.6 Starting the vibration rammer 11
3.6.1 Before start-up 11
3.6.2 Start-up 11
3.6.3 Start-up in closed rooms 12
3.7 Working with the vibration rammer 12
3.7.1 Persons in the danger area 12
3.7.2 Moving the vibration rammer 12
3.7.3 Moving the vibration rammer on slopes 12
3.7.4 Conduct in traffic 12
3.7.5 Checking the effects of vibration 12
3.7.6 Parking the vibration rammer 12
3.7.7 Parking the vibration rammer on slopes 12
3.8 Taking in fuel 13
3.9 Maintenance works 13
3.9.1 Working on the engine 13
3.9.2 Cleaning works 13
3.9.3 After the maintenance works 13
3.10 Repair 13
4.0 Loading and transport
15
5.0 Operation
15
5.1 Control before use 15
5.2 Refuelling 15
5.3 Starting the engine 16
5.4 Cold start device 16
5.5 Working with the vibration rammer 17
5.6 Adjustment during breaks 17
5.7 Stopping the engine 17
6.0 Recommendations for compaction works with DS
68
17
7.0 Maintenance
7.1 General remarks on maintenance/maintenance work 18
7.2 Instructions for running-in 18
7.3 Diesel engine 18
7.4 Changing the oil in the tamping system 19
7.5 Cleaning the diesel filter 19
7.6 Checking, cleaning and replacing the air filter 20
8.0 Screw torques
21
9.0 Maintenance schedule
22
