Ammann ADS 70 - Technical Specifica; Main Dimensions; Technical Specifications

ADS 70 / ACR 70 D 5
Technical specifications :
1.1 Main dimensions ADS 70 / ACR 70 D
Dimension A B C D E
Mm 340 280 670 360 980
Fig. 4
Fig. 5
1.2 Technical specifications ADS 70 / ACR 70 D
Weight 83 kg
Lenght of butt plate 340 mm
Width of butt plate 280 mm
Overall length 670 mm
Overall width 360 mm
Engine Yanmar L48AE diesel engine
with 3.2 kW/4.3 hp at
Engine speed 3250 rpm
Cooling air cooled
Number of impacts 730 min
-1
Jump height up to 60 mm
Surface capacity up to 210 m
2
/h
Impact force 16 kN
Impact energy 95 J
Travel speed up to 12 m/min
Filling capacities :
Fuel tank 2,5 l
Oil inside the butt plate 1,5 l
