Maintenance 111
1201281 A | 24.07.2013
Fig. 9-27 Air filter cartridge
Air intake 1 Check the air intake for:
2a Damage: replace the cowling.
2b Soiling: clean the air intake.
Fig. 9-28 Air intake
9.13.5 Seat contact and emergency stop
1 Put the operating lever into the neutral position.
2 Sit on the driver’s seat.
3 Start the engine.
Brake light (P)
3.1 The brake light (P) must extinguish at once.
4 Leave the seat.
4.1 After 0.7sec., the brake light must light.
5 Switch off the engine.
NOTE The emergency stop control lamp only lights when the emergency stop is
pressed.
