13.1 Introduction
The roller must be disposed of properly; ask your authorized dealer.
13.2 Removal and depressurization of the gas strut
In case of disposal, pressurized gas struts must be depressurized according to the
following regulations:
1 Fasten the pressurized tube between two prismatic jaws without deforming it
and in such a way that the dimension X is at least 25mm (see below).
2 To depressurize:
2a Slowly cut the pressurized tube open at the points indicated using a handsaw
or,
2b Drill a hole in the tube using a drill with about a 3 mm diameter.
CAUTION
Environmental hazard through operating materials!
• Do not allow any liquids to enter drains, the soil or the
environment.
WARNING
Eye injury!
Because of the high internal pressure, chips and oil can
spatter from the site of sawing or drilling.
• Wear eye and face protection.
• Cover the site of the saw cut.
CAUTION
Environmental hazard through operating materials!
Gas struts are filled with oil.
• Do not allow any liquids to enter drains, the soil or the
environment.
