Options 79
1201281 A | 24.07.2013
8.13 Brake warning buzzer
The warning buzzer is active as soon as the seat contact is activated. The warning
buzzer sounds until the locking brake catches.
8.14 Battery cut-off switch
The battery cut-off switch interrupts the power supply from the battery to the roller.
Switch off the battery cut-off switch if the roller is not in operation for longer than two
days.
NOTE Always disconnect the power supply when working on the electrical system.
8.14.1 Switching battery cut-off switch on / off
The battery cut-off switch is located at the rear on the battery plate.
Switching on
the power
1 Turn the red key of the battery cut-off switch left to horizontal position.
If fitted, the roller is now supplied by the starter battery.
Fig. 8-10 Switching onthe power
DANGER
Rollover hazard when driving the roller!
• Get out of the danger zone immediately!
• Personnel may not stand in front of or behind the roller while it
is in operation.
