Ammann ARX 20 - Switching on Continuous Sprinkling; Switch on Interval Sprinkling

66 ARX 1
1201281 A | 24.07.2013
Fig. 7-6 Water tank cover rear right
7.12.3 Switching on continuous sprinkling
On the instrument
panel
1 Turn the sprinkler switch from Pos. 0 to Pos. 1.
The sprinkler switches on.
On the operating
lever
1 Press the bottom button (1).
The sprinkler stays on as long as you are pressing the button.
NOTE In the combined roller, operating lever sprinkling is used only for tire
sprinkling.
7.12.4 Switch on interval sprinkling
1 Turn the interval sprinkling switch from Pos. 0 to Pos. 1.
The sprinkler switches on.
2 Turn the switch further to the right.
The interval sprinkler switches on.
3* Interval times: Turn the switch continuously toward the right to adjust the
sprinkling intervals infinitely.
