Options 81
1201281 A | 24.07.2013
8.15 Temperature sensor
8.15.1 Operation
The measured value is displayed as soon as the ignition is switched on.
Fig. 8-13 Temperature display
If more than one error or notice message is displayed at the same time, the display
switches every 5 seconds.
The standard display unit is ° Celsius.
° Celsius can be switched to ° Fahrenheit by accessing the machine’s controller.
Please contact your dealer in this case.
For deliveries to America, this is already done at the factory.
8.15.2 Troubleshooting
If the measured value deviates significantly from the expected value, an attempt
should be made to clean the lens of the sensor.
The sensor is located on the lower section of the rear chassis.
Fig. 8-14 Temperature sensor
For test purposes, it is recommended that the machine be placed on a surface with
a known temperature.
