Ammann ARX 20 - Tightening Torque: Extremely Low-Profile Cheese-Head Screws; Tightening Torque: Button Socket Cap Screws (M8 Size Without Flange, ISO 7380); Tightening Torque: Countersunk Head Screws; Tightening Torque: Shoulder Screws

118 ARX 1
1201281 A | 24.07.2013
Tab. 9-5 Tightening torque: Extremely low-profile cheese-head screws
Tab. 9-6 Tightening torque: Button socket cap screws (M8 size without flange, ISO 7380)
Tab. 9-7 Tightening torque: Countersunk head screws
Tab. 9-8 Tightening torque: Shoulder screws
19 10 M12 8.8 84
19 10 M12 10.9 123
19 - M14x1.5 10.9 246
22 12 M14 8.8 133
24 14 M16 8.8 206
24 - M16 10.9 302
30 - M20 8.8 415
30 - M20 10.9 592
Allen key
size
Screw
diameter
Steel quality
Tightening torque in
Nm
3 M5 10.9 3
3 M6 10.9 6
4 M8 10.9 13
5 M10 10.9 25
Allen key
size
Screw
diameter
Steel quality
Tightening torque in
Nm
2.5 M4 10.9 2.5
3 M5 10.9 5
4 M6 10.9 8
5 M8 10.9 12
Allen key
size
Screw
diameter
Steel quality
Tightening torque in
Nm
3 M5 10.9 3.8
4 M6 10.9 6.6
5 M8 10.9 16
Allen key
size
Screw
diameter
Steel quality
Tightening torque in
Nm
6 M10 12.9 43
AF
size
hex
AF
size
Hex
socket
Screw diameter Steel quality
Tightening torque in
Nm
