4.9.6. Protective shield adjustment
The machine can be ordered with a protective
shield made of transparent plastic material.
Proceed as follows to adjust the protection
shield:
1. loosen the screw knobs fixing the protection
and lift or lower it at an height of about
6-8 mm from the mouldings to be assembled;
2. tighten knobs to lock the protection shield.
Even if the protective shield is properly
adjusted, it is necessary to respect the
following instructions:
• keep the fingers away from the frontal and
vertical clamp working area
• disconnect the pressure supply during any
maintenance intervention
• keep the foot separated from the pedal during
the machines adjustments
4.10 OPERATIONS TO BE CHECKED
BEFORE STARTING YOUR WORK
Once the machine has been properly installed
(like previously described), check that:
• The mouldings to be assembled are properly
positioned on the working bench
• The magazine is loaded with the type of
nails suitable with the mouldings to be
assembled
• The adjustment of vertical and horizontal
clamping is correct (chapter 4.9.2 and 4.9.3)
• The machine is connected to the electric
network,air and the switches are activated
• The working pressure is adequate to the
wood hardness (see chapter 4.9.5)
• The protective shield is properly positioned
(see chapter 4.9.6)
• Press the pedal full down to activate the
machines cycle
Opening the shield causes the control
pedal deactivation.
