10.2 SPARE PARTS ORDERING
We remind you that only a qualified technician can repair the machine.
Thus, we suggest the intervention of AMP’s or your local distributor’s Center of Technical
Assistance, which has the qualified staff, proper equipment and tools, and uses original spare
parts.
To order the spare parts listed above, send by fax or letter (see chapter 7.3) the following data:
- Model of the Machine
- Code of mechanical drawing
- Reference number of spare part or group indicated on the mechanic drawing
- Code/part number of single or group spare part
11.1 DEMOLITION
At the act of demolition it is necessary to separate the parts in plastic material from electric components.Most countries
require this, respecting the current Norms.
Concerning the machine metallic mass, it is enough the subdivision between the steel parts and those of other metals or
alloys, for a proper recycling by smelting.
11. DEMOLITION
12.1 DECLARATIONS
You can find here attached the following declarations:
t Declaration of conformity to the Norm 89/392/CEE
t Declaration of conformity to the Norm 89/336/CEE
12.2 SCHEMES
You can find here attached the following schemes:
t (A) Mechanic Schemes
t (B) Pneumatic Scheme
t (C) Plates Dislocation
t (D) Sharpening Table
t (E) Electric Scheme
12. ATTACHMENTS
10.1 SPARE PARTS LIST
Even if the machine has been submitted to several tests and functional checks, we list here below
the components and relative amounts (in brackets) that we suggest to have a minimum and
sufficient set of spare parts to guarantee the least amount of down time as possible.
COMPONENT
V-NAILS DRIVER BLADE
V-NAILS CLAW HEADS
“L” SHAPED SUPPORT (V-NAILS GUIDE)
VALVES-REDUCERS-REGULATORS
VERTICAL AND HORIZONTAL CLAMPING GASKETS
10. SPARE PARTS
