24
5.7 MACHINE STOP
The machine can work only by pressing the
electric pedal; to stop it mid-cycle press the
red emergency stop button on the keypad.
It is possible also to disconnect the fast
clutch fitting from the compressed air or isolate
electrically the machine by the special switch
located on the floor stand.
5.8 PUTTING OUT OF SERVICE
In case on long inactivity periods it is
necessary to disconnect the fast clutch fitting
from pneumatic system and the power supply
cable.
b) Assembling positions
It is advisable to operate as follows in order
to achieve the best results in terms of junction
quality:
• Never drive V-nails near the junction vertex.
The minimum recommended distance from the
external vertex is at least 10 mm.
• When you want to make the junction using
only one V-nail, the most suitable position
is in the center of the moulding.
• In case you want to insert 2 or more V-
nails into each junction, we recommend you
to insert the most external one 1/3 from the
external vertex and the most internal one
1/4 from the internal vertex.
