ATTACHMENT B - PNEUMATIC SCHEME
Ref. Description Code Number
1 Pressure Regulator 735630003
2 Pressure Gauge 734230003
3 Lever-Valve 732140001
4A Solenoid Valve 732440023
4B Solenoid Valve 732440023
4C Solenoid Valve 732440023
5 Exaust Valve 732390003
6 Exaust Valve 732390003
7 Exaust Valve 732390003
8 Exaust Valve 732390003
9 Filter-Lubricator 735330001
10 Valve 732440016
11 Foot pedal 258710020
Ref Description Code Number
