AmpliVox Otowave 102 User Manual

Page 34 OM001-16 Otowave 102 Operating Manual
Display mode
Records listed in reverse chronological
order (latest first), with indication of data
stored as described above
Real Time Clock
Time stamps
Time and date stamp applied to all
recordings, and to the last calibration
date
Backup power supply
> 30 days without main batteries fitted
Languages
Operating Languages
English, German or French
Printing
Supported printer
Martel MCP8830,Able AP1300 or
Sanibel MPT-II
Interface
Infra-red, IrDA hardware, 9600 baud
Information printed
Tympanogram, Tympanogram analysis
parameters, Reflex graphs, Reflex
analysis parameters, Serial Number of
device, Last and Next Due Calibration
dates; space for patient & clinician’s
details to be entered.
Serial Interface to computer
Interface
OBEX (Object Exchange) service
running on top of IrDA stack. Auto-
selects between 9600-115200 baud.
Information sent
Patient header, left and right ear data.
Power Supply
Battery Types
4 AA cells; either Alkaline (1.5V
nominal) or NiMH rechargeable (1.2V
nominal, which must be 2.3 Ah capacity
or greater).
Warm-up period
None at room temperature
Number of recordings from one
set of cells
Approx. 200 (Alkaline) or 100 (NiMH)
Auto power-off delay
90 or 180 seconds
Idle current
70mA
Current while testing
230mA
Physical
Display
128 x 64 pixels / 8 lines of 21
characters
Dimensions
190mm long x 80mm wide x 40mm high
