Page #13 background imageLoading...
Page #13 background image
13
340
Series
Specifications
340 Series Specifications
Parts
Specifications
B/T340A
B/T340B
B/T340A-LED
B/T340B-LED
Extreme WF Eyepiece
WF10X/18mm x x x x
WF10X/18mm w/ Pointer
WF10X/18mm w/ Reticle
WF16X/13mm x x
WF20X/10mm x x
WF25X/10mm x x
DIN Achromatic Objectives
4X/0.10 x x x x
10X/0.25 x x x x
40X(spring)/0.65 x x x x
60X(spring)/0.85
100X(spring, oil)/1.25 x x x x
DIN Plan Objectives
4X
10X
40X(spring)
100X(spring, oil)
30 Degree Viewing Head
Binocular Sliding, 360 Degree Swiveling x (if B-) x (if B-) x (if B-) x (if B-)
Trinocular Sliding, 360 Degree Swiveling x (if T-) x (if T-) x (if T-) x (if T-)
Trinocular Port
C-Mount Photoport
x (if T-) x (if T-) x (if T-) x (if T-)
23mm Photo Port
x (if T-) x (if T-) x (if T-) x (if T-)
Focusing
Nosepiece
Coaxial Focusing System x x x x
Quadruple Nosepiece x x x x
Stage
120mm x 110mm Mechanical Stage x x x x
Movement Range: 70mm x 30mm x x x x
Condenser
Abbe, NA= 1.25 x x x x
Diaphragm
Iris Diaphragm x x x x
Illumination
Halogen x x
LED x x
Lamp
6V/15W x x
LED x x
Filter
Blue/Yellow/Green x x
Blue x x
