ADE9000 Technical Reference Manual UG-1098
Rev. 0 | Page 61 of 86
Address Name Description Reset Access
No load threshold in the total and fundamental reactive power datapath.
0x41E APP_NL_LVL No load threshold in the total and fundamental apparent power datapath. 0x0000FFFF R/W
0x41F PHNOLOAD Phase no load register. 0x00000000 R
0x420 WTHR Sets the maximum output rate from the digital to frequency converter for the
total and fundamental active power for the CFx calibration pulse output. It is
recommended to write WTHR = 0x0010_0000.
0x0000FFFF R/W
0x421 VARTHR Sets the maximum output rate from the digital to frequency converter for the
total and fundamental reactive power for the CFx calibration pulse output. It is
recommended to write VARTHR = 0x0010_0000.
0x0000FFFF R/W
0x422 VATHR Sets the maximum output rate from the digital to frequency converter for the
total and fundamental apparent power for the CFx calibration pulse output. It is
recommended to write VATHR = 0x0010_0000.
0x0000FFFF R/W
0x423 LAST_DATA_32 This register holds the data read or written during the last 32-bit transaction on
the SPI port.
0x00000000 R
This register allows any ADC output to be redirected to any digital datapath.
0x425 CF_LCFG CFx calibration pulse width configuration register. 0x00000000 R/W
0x472 PART_ID This register identifies the IC. If the ADE9000_ID bit = 1, the IC is the ADE9000. 0x00100000 R
Temperature sensor gain and offset, calculated during the manufacturing process.
0x480 RUN Write this register to 1 to start the measurements. 0x0000 R/W
0x481 CONFIG1 Configuration Register 1. 0x0000 R/W
0x482 ANGL_VA_VB Time between positive to negative zero-crossings on Phase A and Phase B voltages. 0x0000 R
0x483 ANGL_VB_VC Time between positive to negative zero-crossings on Phase B and Phase C voltages. 0x0000 R
0x484 ANGL_VA_VC Time between positive to negative zero-crossings on Phase A and Phase C voltages. 0x0000 R
0x485 ANGL_VA_IA Time between positive to negative zero-crossings on Phase A voltage and current. 0x0000 R
0x486 ANGL_VB_IB Time between positive to negative zero-crossings on Phase B voltage and current. 0x0000 R
0x487 ANGL_VC_IC Time between positive to negative zero-crossings on Phase C voltage and current. 0x0000 R
0x488 ANGL_IA_IB Time between positive to negative zero-crossings on Phase A and Phase B current. 0x0000 R
0x489 ANGL_IB_IC Time between positive to negative zero-crossings on Phase B and Phase C current. 0x0000 R
0x48A ANGL_IA_IC Time between positive to negative zero-crossings on Phase A and Phase C current. 0x0000 R
0x48B DIP_CYC Voltage RMS½ dip detection cycle configuration. 0xFFFF R/W
0x48C SWELL_CYC Voltage RMS½ swell detection cycle configuration. 0xFFFF R/W
0x48F OISTATUS Overcurrent status register. 0x0000 R
0x490 CFMODE CFx configuration register. 0x0000 R/W
0x491 COMPMODE Computation mode register. 0x0000 R/W
0x492 ACCMODE Accumulation mode register. 0x0000 R/W
0x493 CONFIG3 Configuration Register 3. 0xF000 R/W
CF1 denominator register.
0x495 CF2DEN CF2 denominator register. 0xFFFF R/W
0x496 CF3DEN CF3 denominator register. 0xFFFF R/W
CF4 denominator register.
0x498 ZXTOUT Zero-crossing timeout configuration register. 0xFFFF R/W
0x499 ZXTHRSH Voltage channel zero-crossing threshold register. 0x0009 R/W
0x49A ZX_LP_SEL This register selects which zero-crossing and which line period measurement are
used for other calculations.
0x001E R/W
0x49C SEQ_CYC Number of line cycles used for phase sequence detection. It is recommended to
set this register to 1.
0x00FF R/W
0x49D PHSIGN Power sign register. 0x0000 R
0x4A0 WFB_CFG Waveform buffer configuration register. 0x0000 R/W
0x4A1 WFB_PG_IRQEN This register enables interrupts to occur after specific pages of the waveform
buffer are filled.
0x0000 R/W
0x4A2 WFB_TRG_CFG This register enables events to trigger a capture in the waveform buffer. 0x0000 R/W
0x4A3 WFB_TRG_STAT This register indicates the last page that was filled in the waveform buffer and
the location of trigger events.
0x0000 R/W
