UG-1098 ADE9000 Technical Reference Manual
Rev. 0 | Page 70 of 86
Addr. Name Bits Bit Name Settings Description Reset Access
4
RFNOLOAD
This bit is set when one or more phase
fundamental reactive energy enters or exits the
no load condition. The phase is indicated in the
PHNOLOAD register.
0x0
R/W1
3
AFNOLOAD
This bit is set when one or more phase
fundamental active energy enters or exits the no
load condition. The phase is indicated in the
PHNOLOAD register.
0x0
R/W1
2 VANLOAD This bit is set when one or more phase total
apparent energy enters or exits the no load
condition. The phase is indicated in the
PHNOLOAD register.
0x0 R/W1
1 RNLOAD This bit is set when one or more phase total
reactive energy enters or exits the no load
condition. The phase is indicated in the
PHNOLOAD register.
0x0 R/W1
0 ANLOAD This bit is set when one or more phase total
active energy enters or exits the no load
condition. The phase is indicated in the
PHNOLOAD register.
0x0 R/W1
0x404 EVENT_STATUS [31:17] RESERVED Reserved. 0x0 R
16 DREADY This bit changes from a zero to a one when new
waveform samples are ready. The update rate
depends on the data selected in the WF_SRC
bits in the WFB_CFG register.
0x0 R
15 VAFNOLOAD This bit is set when the fundamental apparent
energy accumulations in all phases are out of no
load. This bit goes to zero when one or more
phases of total apparent energy accumulation
goes into no load.
0x0 R
14 RFNOLOAD This bit is set when the fundamental reactive
energy accumulations in all phases are out of no
load. This bit goes to zero when one or more
phases of fundamental reactive energy
accumulation goes into no load.
0x0 R
13 AFNOLOAD This bit is set when the fundamental active
energy accumulations in all phases are out of no
load. This bit goes to zero when one or more
phases of fundamental active energy
accumulation goes into no load.
0x0 R
12 VANLOAD This bit is set when the total apparent energy
accumulations in all phases are out of no load.
This bit goes to zero when one or more phases
of total apparent energy accumulation goes into
no load.
0x0 R
11 RNLOAD This bit is set when the total reactive energy
accumulations in all phases are out of no load.
This bit goes to zero when one or more phases
of total reactive energy accumulation goes into
no load.
0x0 R
10 ANLOAD This bit is set when the total active energy
accumulations in all phases are out of no load.
This bit goes to zero when one or more phases
of total active energy accumulation goes into no
load.
0x0 R
9 REVPSUM4
This bit indicates the sign of the last CF4 pulse. A
zero indicates that the pulse was from negative
energy and a one indicates that the energy was
positive. This bit is updated when a CF4 pulse is
output, when the CF4 pin goes from high to low.
0x0 R
