UG-1098 ADE9000 Technical Reference Manual
Rev. 0 | Page 74 of 86
Addr. Name Bits Bit Name Settings Description Reset Access
8
ZXTOVC
Set this bit to enable an interrupt when there is a
zero-crossing timeout on Phase C. This means
that a zero-crossing on the Phase C voltage is
missing.
0x0
R/W
7
ZXTOVB
Set this bit to enable an interrupt when there is a
zero-crossing timeout on Phase B. This means
that a zero-crossing on the Phase B voltage is
missing.
0x0
R/W
6 ZXTOVA
Set this bit to enable an interrupt when there is a
zero-crossing timeout on Phase A. This means
that a zero-crossing on the Phase A voltage is
missing.
0x0 R/W
5 VAFNOLOAD Set this bit to enable an interrupt when one or
more phase fundamental apparent energy
enters or exits the no load condition.
0x0 R/W
4 RFNOLOAD Set this bit to enable an interrupt when one or
more phase total reactive energy enters or exits
the no load condition.
0x0 R/W
3 AFNOLOAD Set this bit to enable an interrupt when one or
more phase fundamental active energy enters or
exits the no load condition.
0x0 R/W
2 VANLOAD Set this bit to enable an interrupt when one or
more phase total apparent energy enters or exits
the no load condition.
0x0 R/W
1 RNLOAD Set this bit to enable an interrupt when one or
more phase total reactive energy enters or exits
the no load condition.
0x0 R/W
0 ANLOAD Set this bit to enable an interrupt when one or
more phase total active energy enters or exits
the no load condition.
0x0 R/W
0x407 EVENT_MASK [31:17] RESERVED Reserved. 0x0 R
16 DREADY Set this bit to enable the EVENT pin to go low
when new waveform samples are ready. The
update rate depends on the data selected in
the WF_SRC bits in the WFB_CFG register.
0x0 R/W
15
VAFNOLOAD
Set this bit to enable the
EVENT
pin to go low
when one or more phases of fundamental
apparent energy accumulation goes into no load.
0x0
R/W
14 RFNOLOAD Set this bit to enable the
EVENT
pin to go low
when one or more phases of fundamental
reactive energy accumulation goes into no load.
0x0 R/W
13 AFNOLOAD Set this bit to enable the
EVENT
pin to go low
when one or more phases of fundamental active
energy accumulation goes into no load.
0x0 R/W
12 VANLOAD Set this bit to enable the
EVENT
pin to go low
when one or more phases of total apparent
energy accumulation goes into no load.
0x0 R/W
11
RNLOAD
Set this bit to enable the
EVENT
pin to go low
when one or more phases of total reactive
energy accumulation goes into no load.
0x0
R/W
10 ANLOAD Set this bit to enable the
EVENT
pin to go low
when one or more phases of total active energy
accumulation goes into no load.
0x0 R/W
9 REVPSUM4 Set this bit to enable the
EVENT
pin to go low to
indicate if the last CF4 pulse was from negative
energy. This bit is updated when a CF4 pulse is
output, when the CF4 pin goes from high to low.
0x0 R/W
