4. Click the Probe button on the Probe block to open the
simulation window.
5. Click the Stimulus button on the Stimulus block to begin
the simulation.
6. Move the slider on the Medium-Size Eq block to control
the filter gain. Click on the blue icon at the top of the filter
block to change other parameters of the filter. Notice that
the response of the filter is plotted and changes in real time
(see Figure 34. Simulation ).
Figure 34. Simulation Window
