28
1.  100-240 VAC 2.5A 50/60HZ / FUSE F4A 250 VAC; internal, autoswitchable; 155W
2. : inputs #1 to #4
3.  audio inputs #1 to #2
4.  for audio inputs (balanced) #1 to #4
5.  for audio outputs (balanced) #1 to #2
6.  audio outputs #1 to #2
7.  - 1 x BNC-F: 3G/HD/SD-SDI (with audio embedded)
- 3 x BNC-F: Y-Cb-Cr
- 1 x BNC-F: Composite video PAL/NTSC
8.  HDMI inputs #1 and #2 / HDMI #1 and HDMI #2
9.  HDBaseT inputs #1 to #4
10.  DVI-D inputs #3 and #4. Capability to receive digital audio signal from HDMI connector
via an adaptor (HDMI-compable)
11.  inputs #3 and #4
 HDBaseT LAN interface
 LAN control for device management
 HDBaseT mul-plug outputs #1 and #2
 HDMI mul-plug outputs #1 and #2
 communicaon port with D89 female connector
17.  HDBaseT 5-pin MCO mul-plug output #1 and #2 for InfraRed and Serial
HDBaseT communicaon signals

1
10 118 9
15
17
12 13 14
2 3 4 5
6 7
16
5.1.3 Rear panel SmartMatriX-H - Ref. SMX250-H
