5.1.4 Front panel SmartMatriX²-H - Ref. SMX250-H

1 2 3 4 5
97 108
11
126
1.  4-line VFD

 - Frame: un-scaled layer for sll frames
-  scaled posionable layers for live sources
-  un-scaled, posionable layer for sll logos
4.   select the output #1 or #2, a layer and a source, then press TAKE
5. Adjustment: adjust layer or logo posion, size acve layer, zoom acve layer
6. : hold for 3 seconds for stand-by mode
7.  Home menu or back one level - Enter: validate the menu or command
8.  -  access source 1 to 4, display frame/logo 1 to 4
-  access HDMI®1 or HDMI®2
-  access SDI 1 to SDI 4, display frame/logo 5 to 8
- Quick Frame: allows to quickly display a foreground frame
9.  shorcut to transion menurecall a custom stored preset
10. Layer: - Black: clear the layer
-freeze/unfreeze the input selected in the currently selected layer
11. Step Back: recall the last preset
12. TAKE: transion the pre-selected sources onto the Program output with the selected eects
