The layer layout gives you access to several predened layouts with 2 or 1 PIP already sized and placed into
the output. It can help you to quickly set up 3 PIPs side by side for example. (Number of layers depends on
the used mode.)
Once clicking on the layout buon, you have access to the presets with
2, 1 PIPs or all layouts.
Two other opons are available below:
 layers already displayed and not included into the
chosen layout will be cleared
 layers already displayed and not included into
the chosen layout will be faded out during the transion. They are sll
present on the preset but with a 100% transparency.
Aer selecng the layout, the changes are applied on the selected screen. The size and posion of all layers
are updated. Aer applying a layout template, you can make further modicaons to the layers before Taking
your selecons to Program.

A layer posion shortcut is also available. Aer having selected a layer, simply click on the
 buon to have quickly access to a layer posion. Choose the new posion. The change
is applied straight away on your preset.

You can choose between several aspect rao. Once selected, the new aspect rao is applied
on the selected layer.

 this buon allows you to clear the selected layer from your preset,
 remove all layers from your preset,
set layer size to its content size,
 set layer size to screen size,
 set the layer size to t the source rao,
you need rst to select at less 2 layers, then you can align them horizontally or
vercally (use Shi to select 2 layers),
7.3.4 Background frame
