53
7.4 Live
You can load at any moment a frame or a logo in the same way into a frame or logo layer.
To acvate the QUICK FRAME, simply press the Quick Frame buon (located on the right side of each screen).
Remember that a preset saved into a screen with a 1024x768 resoluon, will keep its size into a screen of
higher resoluon. Therefore, it is best to save preset memories only aer you have congured the output
resoluon.
You sll have access to the preset feature.
Once your preset is ready to send, use the , or the TAKE buon.
You sll have access to STEP BACK buon.
When you use several screens, you have the possibility to load a preset on one or several screens. To TAKE
only one screen separately, select which screens should be aected by the TAKE using this buon:
SEQUENCE:
The sequence feature consists on a meline composed by 16 scenes. Each scene can be lled by a preset
memory. Simply click on MM to choose the memory slot you want to put into the scene.
To select the memory, simply choose it into the list or drag and drop it into the scene box from the memories
selecon (on the right).
This toolbar acts like a command for your meline.
Simply click on play to launch the meline.
You can stop the meline at any moment using the pause or stop buon.
Use the loop buon to load again your meline when it’s nished.
Take a look at the global me of your meline thanks to the clock on the right of the toolbar.
To control the SmartMatriX², Analog Way also provides Crestron and AMX modules. For more details,
see appendices.
