8.2.11 Working with frames

not ll the screen. During the capture, the output is outlined by a white border and includes the pixels into

the white rectangle.



Frames are mainly used as backgrounds in a typical show or event setup, and can be recorded from any of

the SmartMatriX² 10 sources and called back at the press of a single buon. To use a frame, be sure rst that

it is well saved, then:



NOTE: Frames may be used only one at a me and can be placed only in the frame layer.



When transioning sll layers, depending on how many scalers are in use, the SmartMatriX² TAKE funcon

will act in one of 2 dierent ways when transioning the next preset (Preview) to the current preset (Pro-

gram):

TAKE

• All sll frames make an opening and closing phase.

• All sources of the same layer are completely dierent between the current preset and the next preset. The

opening and closing eects of the layer are set to Cut.

TAKE

• One of the layer makes a change of source which is not in Cut.

• The opening and closing phases can be done with dierent eects.

• The sll frame appears and disappears of the layer with the following eects: Cut, Fade, Slide or Wipe.

8.2.13 Frame input setup menu

In the frame input setup menu, you have the possibility to save a frame, and the possibility to erase a stored

frame:





8.2.14 Frames as layer

The frame is considered as a layer and has some sengs available: Pos./Size, Transparency, Opening/Closing

eect, Smooth move and Status.

Those sengs have to be used as layer sengs. Press frame buon to have access to the layer menu sengs.

You can change frame or delete frame on the Preview screen using the same way the layers do:

 

 

Press TAKE to view the result on the Program screen.



The SmartMatriX² oers a wide variety of transions between the scenes you create for your shows and

events. It allows for live recall of 8 user presets, each of which you can edit at any given me.

1. Whether catering for complex event setups, or pung together intricate shows, your SmartMatriX² will

also deliver some of what you could expect from a dedicated mixer, along with its switcher and scaler

capabilies.

Analog way SmartMatriX2 User Manual
