Anderson ROUND BALE WRAPPER HYBRID User Manual

30
the end of the pointer (Figure 8.7 #14). Stop the engine and adjust the actuator lever (Figure
8.7 #15) so that it skims the end of the pointer (Figure 8.7 #14). The automatic system is now
adjusted. Restart the engine and pull the hydraulic stop button (Figure 8.6 #13) to make the
pusher return to its starting position.
Figure 8.7 Hoop actuator lever
15
14
