Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0
Email :
service@grpanderson.com
PARTS LIST
DESCRIPTIONPARTQTYITEM
HUB21062811
WASHER21062912
WASHER21063013
BRAKE SUPPORT210631-114
DRIVE WHEEL BRAKE210634-115
SPRING30400116
CARRIAGE BOLT5005006
7
FLANGE NUT50102468
CARRIAGE BOLT
50050149
FLANGE BOLT
500602410
HYDRAULIC FITTING450973111
MOTOR SUPPORT210719-1112
SPRING
304013113
HYDRAULIC FITTING
451179114
HYDRAULIC FITTING451097115
HYDRAULIC FITTING450712116
CHECK VALVE
465878117
HYDRAULIC MOTOR
469158118
LOCK WASHER502064119
BOLT500004-1 120
TIRE AND RIM481505121
28 - HOOP WHEEL DRIVE
1
12
21
20
19
7
8
9
10
4
2
13
15
17
11
18
16
14
6
5
3
42
