Anderson ROUND BALE WRAPPER HYBRID User Manual

29
Adjusting the Hoop Release
8.6  Place the part (Figure 8.5 #10) at the 7
th
slot from the rear of the machine (Figure
8.5#11).
Figure 8.5 Stopper
8.7  Place the hoop speed control lever at position 0 (Figure 8.6 #12). Press the hydraulic
stop button (Figure 8.6 #13).
Figure 8.6 Valve
8.8 Manually push the pointer toward the front of the machine (Figure 8.7 #14). Start the
engine. Push down the pusher start pedal (Figure 8.1 #1). Stand beside the machine so that
you can see the pointer and the actuator lever (Figure 8.7). Pull the hydraulic stop button
(Figure 8.6 #13). Be prepared for the pusher to move toward the front of the machine and be
ready to push the hydraulic stop button when the actuator lever (Figure 8.7 #15) is in front of
10
11
13
12
