Anderson ROUND BALE WRAPPER HYBRID User Manual

46
Remote control / Control box association
In the case of a lost or broken remote control, you will have to replace it. The new remote
control must be associated with the receiver (Control box). The following procedure allows you
to make the association.
- Remove the Honda engine key.
- Turn on the receiver by pushing the blue button on the.
- Press and hold the start engine button on the remote control.
- Press the button Adress Learn (Figure 12.9) on the receiver.
The signal light (LED) Adress Learn will blink green to indicate that the signal from the remote
has been received and the remote control and the receiver are now associated.
Figure 12.9 Adress Learn button
Descriptions of the LED lights
Signal light functions (LED) from the remote control and the receiver are below:
Remote Control Red LED Green LED
Battery low On Blinking
Normal transmission Off Blinking
Not transmitting properly On On
Engine stopped Blinking Off
Turn off the receiver when you are finished using it to avoid draining the battery of the
wrapper.
Receiver Red LED Green LED Yellow LED
Error on the main contact (Output
diagram)
On Off Off
Reception is ready Off Off Blinking
Receiving a signal Off Blinking Off
