Anderson ROUND BALE WRAPPER HYBRID User Manual

31
Adjusting the Pusher Trigger
8.9  Place the speed control lever at position 0 (Figure 8.6 #12). Push the hydraulic stop
button (Figure 8.6 #13). Start the engine. Push down the pusher start pedal (Figure 8.1 #1).
Stand so that you can see the trigger (Figure 8.9 #17) and the pusher cross bar (Figure 8.9
#18). Pull the hydraulic stop button (Figure 8.6 #13). Let the pusher perform a cycle toward
the front. Be prepared when the pusher returns and push the hydraulic stop button (Figure 8.6
#13) when the pusher cross bar (Figure 8.9 #18) is above the trigger (Figure 8.9 #17). Stop
the engine.
Figure 8.8 Pusher trigger adjustment rod
To adjust the gap (Figure 8.9 #19), you must screw or unscrew the 2 bolts (Figure 8.8 #16) to
move the automatic trigger (Figure 8.9 #17) so that it lightly touches the pusher cross bar
(Figure 8.9 #18). The automatic system is now adjusted. Restart the engine and pull the
hydraulic stop button (Figure 8.6 #13) to make the pusher return to its starting position.
Figure 8.9 Pusher trigger
16
17
18
19
