41
12 OPTIONAL EQUIPMENT
12.1 Work Lights
Two halogen lights installed on the cross bar on the right side of the machine to facilitate
machine operation in the evening or at night. Connected to the machine’s electrical system
(Figure 12.1)(Figure 12.2).
Be aware that the Honda engine must be equipped with a minimum 10 amp alternator for this
option to be successfully installed. If not, your battery will lose its charge and this situation is
not covered by the warranty.
Figure 12.1 Work light
Figure 12.2 Electrical diagram
NOTE:
YOU MUST OPEN THE STARTER BOX TO INSTALL THE SWITCH.
YOU MUST CONNECT THE WIRE TO THE SCREW OF THE STARTER.
SEE THE PARTS BOOKLET.
