Measurements Instruction
Measure AC/DC Voltage
1. Connect the black test lead to the COM Terminal
and the red lead to the VΩHz Terminal.
2. To measure voltage under 99.99mV, push ,
push once to measure DCmV, push twice to
measure ACmV. To measure voltage higher
than 99.99mV, push , push once to measure
DCV, push twice to measure ACV.
3. Touch the probes to the correct test points of
the circuit to measure the voltage.
4. Read the measured voltage on the display.
Measure AC/DC Current
1. Connect the black test lead to the COM Terminal
and the red lead to the AmA Terminal or the μA
Terminal (choose based on the value of the current
to be measured); if the previous setting was
continuity/diode, push any of the three rectangle
buttons on the left once.
*Do not measure voltage that exceeds the extremes
as indicated in the Specifications.
*Do not touch high voltage circuit during measurements.
