10
2. Push to toggle between DCA and ACA.
3. Break the circuit path to be measured, connect
the test leads across the break and apply
power.
4. Read the measured current on the display.
Measure Resistance
1. Connect the black test lead to the COM Terminal
and the test lead to the VΩHz Terminal.
2. Push once to enter the Resistance Mode.
3. Touch the probes to the desired test points of
the circuit to measure the resistance.
4. Read the measured resistance on the display.
*Do not measure current that exceeds the extremes
as indicated in the Specifications.
*Use the AmA Terminal when you are measuring an
unknown current. Then switch to the μA Terminal
if necessary.
*Do not input voltage at this setting.
*Disconnect circuit power and discharge all
capacitors before you test resistance.
*Do not input voltage at this setting.
