Anet A8 Plus - Installation; Step 1: Initial Frame Assembly

Step 1
No.
Name
Qty.
1
X axis aluminum profile 472mm
2
2
Y axis aluminum profile 422mm
2
3
End cap
4
4
Environmentally friendly rubber pillar washer
4
5
M5*20 socket hexagon screw
12
M5*20
Before assembly
After assembly
Front X axis
Rear X axis
The Y axis is separated from the hole position, the
front section is long, and the rear section is short.
Long
Short
