Anet A8 Plus - Installation

Step 21
No.
Name
Qty.
1
Power supply kit
1
2
Mainboard kit
1
Remove the M3 * 6 socket hexagon screw
for fixing the power supply, split the
power supply and power supply fixing
frame, and retain the 3 inner hexangular
set screws.
Split the motherboard kit, retain the 4 m3 * 6 socket hexagon screws, and then install the M4 *
8 socket hexagon screws and T- nuts in the 3 holes on the mainboard.
The circle is an enlarged view
( side ) of the T - nut
installation
Before assembly
After assembly
