Step 23
No.
Name
Qty.
1
KM2*10
2
2
M4*8 cross recessed countersunk screw
2
3
T-nut M4
2
4
Limit switch (without pulley)/Limit switch support
1
5
A8 plus motor line bag
1
6
Heating tube6*20mm( with line 1.5m)
1
7
Hotbed line
1
8
FPC grey ribbon line bag
2
Limit switch support
M4*6
Limit switch
Z1 axis
Z2 axis
Installation diagram of
limit switch support
70mm
The installation position of the Z - axis limit
switch is 80 mm away from the Y - axis profile
