Anet A8 Plus - Page 22

Step 11
No.
Name
Qty.
1
Extruder kit
1
Loosen the nut and exit
the extruder
1. Loosen the nut and separate the extruder from the L-shaped black aluminum .
2..Remove the 2 M3*6 screw and use them later.
Before disassembly
After disassembly
L-shaped black aluminum
Extruder
M3*6
