Anet A8 Plus - Page 29

Step 18
No.
Name
Qty.
1
486mm
Z axis guiding rod 486mm
2
2
462mm
Z axis screw rod 462mm
2
.
Note: Rotate the screw rod clockwise down to the bottom, and
then lock the self-contained top tightening screw
462mm*2
486mm*2
Lock the self-contained top tightening screw
Before assembly
After assembly
