Step 25
According to the schematic diagram of the line port and the label of the wiring, find the corresponding wiring and
plug in all the wiring, the cable with the word "-A" is connected to one end of the mainboard.
Wiring sheet：
Name
Cable label
Mainboard
port
Name
Cable label
Mainboard port
X axis motor
X-Motor-A
X
X axis limit switch
X axis limit switch line-A
S-X
Y axis motor
Y-Motor-A
Y
Y axis limit switch
Y axis limit switch line-A
S-Y
Z1 axis motor
Z1-Motor-A
Z1
Z axis limit switch
Z axis limit switch line-A
S-Z
Z2 axis motor
Z2-Motor-A
Z2
Heating bed
Heating bed-A
BED
E axis motor
E-Motor-A
E
Thermistor-A
B-T
Extruder
Extruder thermistor-A
E-T
TF card
TF card port
Extruder
Extruder heating tube-A
END
power supply
Power supply line-A
+ -
Display screen
LCD grey ribbon cable
-A
LCD
Fan
Fan with line-A
FAN2
Display screen
J3 grey ribbon cable-A
J3
Air blower
Air blower with line-A
FAN1
1. Except that the electronic wire shown in step 6 passes through the jack at the upper end of the mainboard, the remaining
electronic wires are all pulled out from the holes under the mainboard, and the machine is connected from below the machine
to avoid affecting the operation of the machine.
