4200T CNC Programming and Operations Manual
P/N 70000412F - Preparatory Functions: G-Codes
4-2 All rights reserved. Subject to change without notice.
31-July-05
Table 4-1, Modal and Non-Modal G-Codes
Modal Non-Modal
G-Code Function G-Code Function
G0
Positioning-Rapid Traverse
G4
Dwell
G1
Linear Interpolation
G5
Ellipse
G2
Circular Interpolation-CW
G9
Exact Stop Check
G3
Circular Interpolation-CCW
G31
Probe Move
G22
Stored Stroke Limit ON
(Programmable Stroke Limit)
G33
Threading
G24
Spindle Speed Clamp
G65
User Macro Single Call
G40 Tool Tip Radius Compensation,
Cancel
G74
Area Clearance (Face) Cycle
G41 Tool Tip Radius Compensation,
Left of Path
G76
Rough Turning/Boring Cycle
G42 Tool Tip Radius Compensation,
Right of Path
G77
Rough Facing Cycle
G53 Work Coordinate System (1-99,
select)
G78
Peck Drill Cycle
G59
Modal Corner Rounding
G79
Chip Break Drill Cycle
G60
Modal Corner Rounding Off
G81 Longitudinal Grooving Cycle
(Turn)
G61 Exact Stop Check Mode
(Continuous Path OFF)
G82
Face Grooving Cycle
G64 Cutting Mode (Continuous Path
ON)
G83 Longitudinal Thread Cycle,
Plunge
G66
User Macro Modal Call
G84 Longitudinal Thread Cycle,
Compound
G67
User Macro Modal Call Cancel
G85
Face Thread Cycle, Plunge
G68
Coordinate System Rotation
G86
Face Thread Cycle, Compound
G70
Inch Programming
G87
Tapping Cycle
G71
MM Programming
G88
Boring
G72
Axis Scaling
G92
Absolute Zero Preset
G90
Absolute Programming
G91
Incremental Programming
G94
Per Minute Feed
G95
Per Revolution Feed
G96 Constant Surface Speed
Function (CSS)
G97
Revolutions Per Minute (RPM)
