4200T CNC Programming and Operations Manual
P/N 70000412F - Preparatory Functions: G-Codes
4-12 All rights reserved. Subject to change without notice.
31-July-05
Figure 4-5, Front Tooling Software Limits
Figure 4-6, Rear Tooling Software Limits
Maximum Spindle Speed (G24)
Format: G24 Sxxxx
Refer to Table 4-11.
Table 4-11, G24 Address Words
Address Word Format Description
G24
--- Sets the maximum
programmable spindle speed.
S
xxxx Maximum programmable spindle
speed, maximum four digits.
G24 sets the maximum programmable spindle speed, when the CNC is in
Constant Surface Speed Mode (G96). The G24 command stops the
spindle from accelerating to the machine maximum spindle speed when
facing to the centerline of the part. G24 is not required when using G97
(direct RPM value).
