CNC Setup Utility Manual
P/N 70000490C - Machine Constants
All rights reserved. Subject to change without notice.
10-December-04
2-1
Section 2 - Machine Constants
The Machine Constants configures the settings for the CNC.
Machine Constants Group Assignments
Refer to Table 2-1 for range assignments.
6400M
The Setup Utility displays Machine Constants for axes X, Y, Z, and U.
Machine Constants for the U-axis need to be set when the U-axis is
used in a 6000M-4X.
Table 2-1, Machine Constant Group Assignments
Setup Parameter Group MC Range
Control Software MC_1000 – MC_1099
Draw Mode MC_1100 – MC_1199
User Definable Variables MC_1120 – MC_1149
Tool Probe Variables MC_1150 – MC_1199
Editor Mode MC_1200 – MC_1299
Program Directory MC_1300 – MC_1349
RS-232 Communication MC_1350 – MC_1374
Printer MC_1375 – MC_1399
X-axis Setup MC_2000 – MC_2099
Y-axis Setup MC_2100 – MC_2199
Z-axis Setup MC_2200 – MC_2299
U-axis Setup MC_2300 – MC_2399
Spindle axis Setup MC_2900 – MC_2999
Linear Correction Compensation MC_3000 – MC_3014
Skew Error Compensation MC_3015 – MC_3029
Backlash Compensation MC_3030 – MC_3049
Ballscrew Compensation MC_3050 – MC_3099
Software Limits MC_4000 – MC_4019
Continuous Path MC_4020 – MC_4029
Position Error Check (PEC) MC_4030 – MC_4049
Jog Return Position MC_4050 – MC_4059
Direct Numeric Control (DNC) MC_4060 – MC_4065
Handwheel MC_4100 – MC_4149
Home MC_4200 – MC_4249
Miscellaneous MC_4300 – MC_4399
M-Code Macro Call MC_4400 – MC_4419
Tool Management MC_5000 – MC_5099
Interface MC_5100 – MC_5149
More Parameters MC_5200 – MC_5299
6000M-4X
