CNC Setup Utility Manual
P/N 70000490C - Setup Utility Concepts
All rights reserved. Subject to change without notice.
10-December-04
1-3
Axis Keys
Some parameters require that you specify an axis. Use the X, Y, Z, or U
key to specify the axis.
Console Switches/Manual Panel Keys
Console switches and Manual Panel Keys are referred to as shown in
Table 1-3.
Table 1-3, Console Switches/ Manual Panel Keys
Name Switch/Key
Axis Selector Switch
X
Y
Z
U
AXIS
Jog Selector Switch
FEED
RAPID
Feedrate OVERRIDE Switch
Spindle OVERRIDE Switch
E-Stop Key
Jog Plus Key
Jog Minus Key
Servo Reset Key
Start Key
Hold Key
(Continued…)
SPINDLE
