Table 2-2, Machine Constants Setup (Continued)
Machine Constant
Parameter
Function Settings
Draw Mode Setup Parameters
MC_1100:
Restore Draw to
previous session
Sets the CNC to re-activate the last
active session when you re-enter Draw.
Yes - CNC re-activates last
session when Draw activated.
[Default]
No - CNC ignores parameter.
MC_1101:
Default program block
mode
Sets default mode in Draw.
Auto [Default]
S.Step
Motion
MC_1102:
Display program text
Determines whether program text is
displayed in Draw Mode.
Yes - Shows program text.
[Default]
No - Does not show program text.
MC_1103:
Grid
Activates/deactivates grid as a dotted or
solid line.
None - Deactivates grid. [Default]
Solid - Activates solid line grid.
Dotted - Activates dotted line grid.
MC_1104:
Grid size
Determines the size of the grid (in the
active Inch or MM Mode).
NOTE: The CNC converts the set grid
value if the measurement unit is
changed. For example: if the Grid Size
is set for 1 in Inch Mode and you switch
to MM Mode, the CNC changes the Grid
Size to 25.4 mm (equal to 1 inch).
Range (0.0–25,400.0)
1.0 [Default]
(If the CNC is in Inch Mode, each
square in the grid will be one
square inch in size for this setting.)
MC_1105:
Tool display
Turns the tool display On and Off.
On - The tool (as defined by the
Tool Location Code and
Radius in the Tool Page) will
be displayed as it cuts the
workpiece. [Default]
Off - No tool is displayed.
MC_1106:
Default tool type
Determines shape of displayed tool. None - No tool shown
Flat - Flat-end tool shown [Default]
Ball - Ball-end tool shown
