CNC Setup Utility Manual
P/N 70000490C - Machine Constants
All rights reserved. Subject to change without notice.
10-December-04
2-79
A successful load shows the new entries in the table.
9. Repeat the procedure for the other axes.
Table Entries - Setup
X Y Z
1. 0.00000 0.00000 0.0000
Ballscrew Compensation File Loader
6300M – Setup Utility
Figure 2-2, Ballscrew Compensation File Loader Menu
