3-4 Commands Command Directory
3-122 PN: 10370-10374 Rev. F MG369xC GPIB PM
W3 <value> <unit>
Description: Opens the internal pulse width 3 parameter.
Functional
Category: PARAMETER ENTRY
Value: 30 ns to 167 ms with 100 MHz pulse clock rate;
25 ns to 419 ms at 40 MHz pulse clock rate;
100 ns to 1.6 s at 10 MHz pulse clock rate
Units: SEC, MS, US, NS
Output Command: OW3 (in s)
Front Panel Key: Modulation | Pulse (internal) | Wdth/Dly List. . . | Edit Selected
W4 <value> <unit>
Description: Opens the internal pulse width 4 parameter.
Functional
Category: PARAMETER ENTRY
Value: 30 ns to 167 ms with 100 MHz pulse clock rate;
25 ns to 419 ms at 40 MHz pulse clock rate;
100 ns to 1.6 s at 10 MHz pulse clock rate
Units: SEC, MS, US, NS
Output Command: OW4 (in s)
Front Panel Key: Modulation | Pulse (internal) | Wdth/Dly List. . . | Edit Selected
WFS
Description: Enable synchronization of the internal AM and FM/PM function generators.
Serial command: 0x04b8
Functional
Category: MODULATION
Example: WFS ALW<2-byte binary data for waveform size><2-byte binary data for
waveform data> PLW<2-byte binary data for waveform size><2-byte
binary data for waveform data> WFS
Related
Commands: ALW, FLW, PLW
Front Panel Key: NA
Note The WFS command must be sent before and after any waveform as shown in the example.
