A3 PLUS - OPERATING INSTRUCTION
8. Accessories
8.1. Operating lamp
Theoperatinglampcomesin2models:
Lamp with halogen light source, model VENUS E
Lamp with halogen light source, model VENUS PLUS.
Theinstructionsfor useandmaintenanceofthelampsareavailablein
PDFformatandcanbedownloadedfromthedownloadareaofthewebsite
www.anthos.com.
NOTE: during the automatic movements of the dental chair, the
lamp automatically turns o to prevent blinding the patient.
8.2. Monitor on lamp pole
Theinstructionsforuseandmaintenanceofthemonitorareprovidedwith
the device.
8.3. Negatoscope for panoramas
Anx-raylmviewerforpanoramicx-rayscanbemountedonallINTER-
NATIONALversioninstrumentboards.
Thescreendimensionsareasfollows:H=210mm,L=300mm.
Peraccendereilnegatoscopioèsu󰀩cienteagiresull'appositointerruttore(a ):
 =negatoscopeon.
 =negatoscopeo󰀨.
8.4. Air/water/230V quick-connect couplers
The230Vair/waterquick-connectcouplersarelocatedinthefrontofthe
utility service centre.
WARNING!
Shut o󰀨 the equipment before attempting to connect or disconnect
the air/water outlets.
Technical specications.
•Poweroutlet:230VAC2AinaccordancewithIEC/EN60320-2-2/F(only
ondentalunitswith230VACpowersupply).
•Airquick-connectcouplerpressure:6Bar.
• Water quick-connect coupler pressure:
- municipalwater,2.5Bar
-withS.H.S.system,1,8Bar
-withW.H.E.system,3Bar
• Water quick-connect coupler delivery rate:
-municipalwater,1800ml/min
- with S.H.S. system,950ml/min
-withW.H.E.system,400ml/min
NOTE: with the SHS system, in order to use the quick-coupling
with mains water, the distilled water tank needs to be disabled (see
paragraph 7.2.).
